Key Features
| Sizes (mm) | Standard | Welding Position | Shielding Gas | Polarity | |
|---|---|---|---|---|---|
| 0.08~1.6 | AWS A5.20 AWS A5.36 KS D 7104 JIS Z 3313 EN ISO 17632-A EN ISO 17632-B | E71T-GS E71T14S-AZ-CS3 YFW-S50GB T49 TG-1NS T42 Z V NO 1 T49 Z TG-1NOS | F, HF, H, VU, VD, OH | Non | DC(-) |
| Typical chemical composition all-weld metal (%) | ||||||||
|---|---|---|---|---|---|---|---|---|
| C | Si | Mn | P | S | Cr | Ni | Mo | Remark |
| 0.10 | 0.12 | 0.53 | 0.014 | 0.006 | – | – | – | Al 1.23 |
| Typical mechanical properties of all-weld metal | |||||
|---|---|---|---|---|---|
| Y.S (MPa) | T.S (MPa) | EI. (%) | Hardness (HV) | IV (J) | PWHT |
| 489 | 520 | 22 | – | – | – |
